TARAWA CLASS LHA SHIP 7240 INCANDESCENT LAMP CM8-1098 SMB567899 6240-00-176-5648
TARAWA CLASS LHA SHIP 7240 INCANDESCENT LAMP CM8-1098 SMB567899 6240-00-176-5648
Regular price
$25.00 USD
Regular price
Sale price
$25.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
NSN 6240-00-176-5648 Specs and cross-references for NSN 6240-00-176-5648 (opens in a new tab) ↗
Chicago Miniature Lighting CM7240 Incandescent Lamp (NSN 6240-00-176-5648)
Chicago Miniature Lighting CM7240 incandescent lamp, T-1 bulb, colorless light output.
Part Information
- Manufacturer: Chicago Miniature Lighting LLC
- Part Number: CM7240
- NSN: 6240-00-176-5648
Specifications
- Overall Length: 0.380 in. max
- Filament Designation: C-2F
- Light Output: 0.100 spherical candlepower nominal
- Average Life Rating: 10,000 hours
- Light Center Length: 0.190 in. nominal
- Voltage Rating: 10.000 V nominal
- Wattage Rating: 0.270 W
- Bulb Designator: T-1
- Bulb Light Transmission: Transparent
- Current Rating: 0.027 A nominal
- Emitted Light Characteristic: Colorless
