13213E6940 Soil Testing Sampling Collar (6635-00-371-9689)
Steel mechanical seamless tubing sampling collar, cadmium plated, with a case-hardened cutting edge.
Part Information
- Design Control Activity: CECOM LR CENTER
- Part Number: 13213E6940
- NSN: 6635-00-371-9689
- CAGE Code: 97403
Specifications
- Material: Steel tubing, mechanical, seamless, AISI 1018
- Plating: Cadmium plated per Q-P-416, Type 2, Class 1
- Cutting edge: Case hardened to Rockwell 15N 80-83, 0.015-0.030 in. deep
- OD: 6.500 in.
- ID at cutting edge: 5.958 in. min, 5.978 in. max
- Cutting edge angle: 70.0 deg taper
