M939A2 8.3L Engine Sequel 12363275 Rr Engine Mount Rubber Bushing | NSN 5342-01-331-7985
M939A2 8.3L Engine Sequel 12363275 Rr Engine Mount Rubber Bushing | NSN 5342-01-331-7985
Regular price
$168.96 USD
Regular price
Sale price
$168.96 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
NSN 5342-01-331-7985 Specs and cross-references for NSN 5342-01-331-7985 (opens in a new tab) ↗
HARSCO CORPORATION 2051 0070 Resilient Weapon System Mount (NSN 5342-01-331-7985)
Two-matched-section resilient mount with steel bushing and steel washer components, for the M939A2.
Part Information
- Manufacturer: Harsco Corporation
- Part Number: 2051 0070
- NSN: 5342-01-331-7985
- End Item: M939A2
- CAGE Code: 47457
Specifications
- Inside Diameter: 0.656 in nominal
- Major Outside Diameter: 2.900 in nominal
- Height: 5.040 in nominal
- Nonmetallic Hardness: Shore Durometer A 55.0–65.0
- Special Features: Item made in 2 matched sections
- Material, Bushing: Steel (ASTM A513, CO-126, TYPE 5)
- Material, Washer: Steel (ASTM A569 or ASTM A366)
