M1167 TOW TRUCK 12561434-129 2A HEXAGON HEAD CAP SCREW 12561434 5305-01-693-7470
M1167 TOW TRUCK 12561434-129 2A HEXAGON HEAD CAP SCREW 12561434 5305-01-693-7470
Regular price
$25.00 USD
Regular price
Sale price
$25.00 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
NSN 5305-01-693-7470 Specs and cross-references for NSN 5305-01-693-7470 (opens in a new tab) ↗
12561434-129 Hexagon Head Cap Screw (5305-01-693-7470)
Steel hexagon head cap screw, SAE J429 Grade 8, for the M1167 TOW TRUCK.
Part Information
- Design Control Activity: U.S. Army Tank Automotive Command
- Part Number: 12561434-129
- NSN: 5305-01-693-7470
- End Item: M1167 TOW TRUCK
Specifications
- Thread Class: 2A
- Thread Direction: Right-Hand
- Thread Series: UNF
- Nominal Thread Diameter: 0.375 in
- Threads Per Inch: 24
- Thread Length (min): 0.625 in
- Fastener Length (nominal): 1.750 in
- Head Height (nominal): 0.2815 in
- Width Between Flats (nominal): 0.5625 in
- Material: Steel, SAE J429 Grade 8
- Special Features: Finish per IAW Drawing 12469117
