M-109 Inflation Systems 7388571 Quick Disconnect Coupling Assy 4730-00-738-8571

E.C.A ETABLISSEMENT 4730007388571 Quick Disconnect Coupling Assembly (4730-00-738-8571)

Steel quick disconnect coupling assembly with spring push-pull disconnect, for the M-109 Inflation Systems.

Part Information

• Manufacturer: E.C.A ETABLISSEMENT
• Part Number: 4730007388571
• NSN: 4730-00-738-8571
• End Item: M-109 Inflation Systems

Specifications

• Overall Length: 3.594 in. min / 3.625 in. max
• Quick Disconnect Method: All ends, spring push-pull
• Quick Disconnect Nominal Size: All ends, 0.500 in.
• Maximum Operating Temp: 150.0°F
• Leg Length: 0.453 in. nominal
• Connection Type: First fluid end, threaded internal pipe
• Nominal Thread Size: 0.375 in.
• Operating Pressure: Max 2000 PSI
• Material: Steel (overall)
• Surface Treatment: Cadmium or zinc
• Thread Series: NPT
