| FREQUENCY RATING |
60.0 HERTZ NOMINAL SINGLE COMPONENT |
| INPUT-OUTPUT PHASE RELATIONSHIP |
SINGLE PHASE TO SINGLE PHASE SINGLE COMPONENT |
| MAXIMUM TRANSFORMER POWER RATING |
3.0 KILOVOLT-AMPERE SINGLE COMPONENT |
| WINDING SHIELDING METHOD |
INTERNALLY SHIELDED SINGLE COMPONENT |
| BODY WIDTH |
6.750 INCHES NOMINAL |
| BODY HEIGHT |
15.375 INCHES NOMINAL |
| INCLOSURE TYPE |
FULLY INCLOSED WITH OIL |
| MOUNTING FACILITY QUANTITY |
4 SINGLE GROUP |
| MOUNTING METHOD |
SLOT SINGLE GROUP |
| WINDING FUNCTION AND QUANTITY |
2 PRIMARY SINGLE COMPONENT AND 2 SECONDARY SINGLE COMPONENT |
| WINDING OPERATING VOLTAGE |
120.00 AC POUNDS PER HOUR WET SINGLE COMPONENT 1ST SECONDARY |
| WINDING OPERATING VOLTAGE |
240.00 AC POUNDS PER HOUR WET SINGLE COMPONENT 2ND SECONDARY |
| WINDING OPERATING VOLTAGE |
240.00 AC POUNDS PER HOUR WET SINGLE COMPONENT 1ST PRIMARY |
| WINDING OPERATING VOLTAGE |
480.00 AC POUNDS PER HOUR WET SINGLE COMPONENT 2ND PRIMARY |
| TERMINAL TYPE AND QUANTITY |
8 WIRE LEAD |
