• Radio System Freed Transformer ANTRC170 NSN 5950-00-118-1018
  • Radio System Freed Transformer ANTRC170 NSN 5950-00-118-1018 - photo 2
  • Radio System Freed Transformer ANTRC170 NSN 5950-00-118-1018 - photo 3
  • Radio System Freed Transformer ANTRC170 NSN 5950-00-118-1018 - photo 4
1 4

SECO Parts and Equipment

ANTRC170 RADIO SYSTEM FREED TRANSFORMER 39413 POWER TRANSFORMER 5950-00-118-1018

ANTRC170 RADIO SYSTEM FREED TRANSFORMER 39413 POWER TRANSFORMER 5950-00-118-1018

$254.93 USD
$254.93 USD
Sale Sold out
Shipping calculated at checkout.

NSN 5950-00-118-1018 Specs and cross-references ↗

MAGNESPEC INC C1-13474 Power Transformer (5950-00-118-1018)

Hermetically sealed single-phase power transformer for the AN/TRC-170 Radio System.

Part Information

  • Manufacturer: Magnespec Inc
  • Part Number: C1-13474
  • NSN: 5950-00-118-1018
  • End Item: AN/TRC-170 Radio System

Specifications

  • Enclosure: Hermetically sealed
  • Winding: Single primary, single secondary
  • Primary Voltage: 208.00 VAC nominal
  • Secondary Voltage: 30.00 VAC nominal
  • Secondary Current: 1.8 A AC maximum
  • Frequency: 60.0 Hz nominal
  • Body: 2.750" L x 2.320" W x 3.120" H
  • Mounting: 4 threaded studs, single group
  • Mounting Spacing: 1.500" x 1.000" (center to center)
  • Thread: 0.138" dia, 32 TPI, UNC
  • Terminals: 4 solder studs
View full details
